Features&Benefits
The Tiger-CC-Maximum Duty Elevator Bucket was designed to combine the style of the traditional CC elevator bucket with the ruggedness and toughness of the Tiger-Tuff elevator bucket. This will increase bucket life and provide less breakage and more capacity. The most common applications include grain, fertilizers, pellets, corn, wheat, soybeans and other agricultural and light industrial applications. The recommended belt width for a single row of buckets is actual bucket width plus 2″.
FEATURES
- Traditional CC Style w/ High Sides and
- Breaks in the Bottom of Bucket
- Thicker Corners
- Thicker Walls, Heavy Front Lip for Digging
- Cleaner Discharge
- Heat, Impact & Abrasion Resistant
BENEFITS
- Non-Corrosive, Non-Sparking
- Extends Bucket Life
- Increases Elevator Capacity
- Lowers Elevator Maintenance
- Decreases Elevator Down Time
Size Chart
MOUNTING HOLES AND VENTING TO YOUR SPECIFICATIONS
| Bucket Size, Inches | Punching, Inches | Weight, Lbs. | Capacity, Cu. Inches | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | Length (L) | Proj. (P) | Depth (D) | Back Wall Thickness | Centers (E) | # Of Holes | Bolt Size | Top Down | Polyethylene | Nylon | Urethane | Water Level X-X | Water Level +10% | Std. Spacing |
| 12×8 | 12 7/8 | 9 1/4 | 8 7/8 | 0.55 | 3 3/8 | 4 | 5/16 | 2 | 4.90 | – | – | 366.00 | 403.00 | 10 |
| 14×8 | 14 7/8 | 9 1/4 | 8 7/8 | 0.55 | 3 | 5 | 5/16 | 2 | 5.40 | – | – | 430.00 | 473.00 | 10 |
| 16×8 | 16 7/8 | 9 1/4 | 8 7/8 | 0.55 | 2 7/8 | 6 | 5/16 | 2 | 5.90 | 6.78 | – | 510.00 | 561.00 | 10 |
| 18×8 | 18 7/8 | 9 1/4 | 8 7/8 | 0.55 | 3 1/8 | 6 | 5/16 | 2 | 6.60 | 7.70 | – | 560.00 | 616.00 | 10 |
| 20×8 | 20 7/8 | 9 1/4 | 8 7/8 | 0.55 | 3 1/2 | 6 | 5/16 | 2 | 7.20 | 8.15 | 9.58 | 655.00 | 720.00 | 10 |
| 20×10 | 21 | 11 1/2 | 10 3/8 | 0.70 | 3 1/2 | 6 | 3/8 | 2 1/4 | 12.20 | 14.20 | – | 1005.00 | 1106.00 | 12 |
| 21×10 | 22 | 11 1/2 | 10 3/8 | 0.70 | 3 5/8 | 6 | 3/8 | 2 1/4 | 12.60 | – | – | 1055.00 | 1161.00 | 12 |
| 22×10 | 23 | 11 1/2 | 10 3/8 | 0.70 | 4 | 6 | 3/8 | 2 1/4 | 13.00 | 14.30 | – | 1105.00 | 1216.00 | 12 |
| 23×10 | 24 | 11 1/2 | 10 3/8 | 0.70 | 3 3/8 | 7 | 3/8 | 2 1/4 | 13.50 | – | – | 1155.00 | 1271.00 | 12 |
| 24×10 | 25 | 11 1/2 | 10 3/8 | 0.70 | 3 1/2 | 7 | 3/8 | 2 1/4 | 14.00 | 16.13 | – | 1206.00 | 1327.00 | 12 |
| 25×10 | 26 | 11 1/2 | 10 3/8 | 0.70 | 3 5/8 | 7 | 3/8 | 2 1/4 | 14.40 | – | – | 1256.00 | 1381.00 | 12 |
| 26×10 | 27 | 11 1/2 | 10 3/8 | 0.70 | 3 7/8 | 7 | 3/8 | 2 1/4 | 14.80 | 17.00 | – | 1306.00 | 1437.00 | 12 |
| 27×10 | 28 | 11 1/2 | 10 3/8 | 0.70 | 3 3/8 | 8 | 3/8 | 2 1/4 | 15.30 | – | – | 1356.00 | 1492.00 | 12 |
| 28×10 | 29 | 11 1/2 | 10 3/8 | 0.70 | 3 5/8 | 8 | 3/8 | 2 1/4 | 15.80 | 18.13 | – | 1400.00 | 1540.00 | 12 |
| Available upon request – extended lead time required |
** Actual dimensions may vary slightly on all elevator buckets, depending on specified raw material.
Available Materials
| Materials | Polyethylene | Nylon | Urethane | FDA Nylon |
|---|---|---|---|---|
| Color |  Orange |
 Tan |
 Green |
 White |
| Application | Grain & Food Products | Hot, high impact, abrasive dense products | Heavy abrasion, sticky materials | Hot, high impact, abrasive food grade products |
| Temperature Range | -120°F to +180°F (210°F intermittent) |
-60°F to +300°F (350°F intermittent) |
-60°F to +180°F (210°F intermittent) |
-60°F to + 300°F |
| FDA Approved Material | Yes | No | Yes | Yes |
| Comments | Economical, high density polyethylene. FDA approved material for handling food grade products. | Best for high heat applications, with tough impact and abrasion needs. | Most flexible and abrasion resistant. Resists product sticking and sharp cutting particles. | Best for high heat food grade applications, with tough impact and abrasion needs. |
